iOptron SkyHunter Compact Dual GoTo Mount -with tripod Alt-Az Package - SHAZ
Couldn't load pickup availability
Product details
- SKU IOP-SHAZ
Meet the SkyHunter, the lightest and most compact full function portable goto mount yet created by iOptron. Weighing in at only 2.9 lb. (including internal rechargeable battery), the SkyHunter is capable of supporting an 11 lb. payload in both equatorial and alt-azimuth modes.
The iOptron SkyHunter mount features four tracking rates: 1X or sidereal, 1/2X for sky and landscape combined, solar and lunar. All 4 tracking rates work in both northern and southern hemispheres.
The iOptron SkyHunter mount can be controlled by an iOS or Android SmartPhone or tablet, the optional 8410 hand controller, or a computer via ASCOM, INDI or embedded drive.
This version of the SkyHunter is for alt-azimuth use. It comes with the SkyHunter AZ head, counterweight, the iOptron 3221 tripod and the 8041 pier extension. While you can use a tripod with the appropriate head to set up the SkyHunter equatorially, this version does not come with the SkyHunter EQ Base. For versions that do include the EQ Base, see the SHEQ and the SHEQA with iPolar.
- Specialized Grab N’ Go GOTO EQ/AZ mount
- Mount weighs 2.9 lbs (1.3kg)
- Payload 11 lbs (5kg) (balanced, exclude CW)
- Dual-axis servomotors with optical encoders
- Tracking speed: solar, lunar, 1X, 1/2X, S/N
- Operation in both northern and southern hemisphere
- Vixen dovetail saddle
- Built-in rechargeable battery for up to 10 hours of operation (20°C)
- Built-in WIFI adapter for full ASCOM, iOptron CommanderTM and Sky Safari control
- USB port for firmware upgrade and computer control
- Optional Go2Nova® 8410 controller with Advanced GOTONOVA® GOTO Technology
- Counterweight Shaft: Φ20X200mm with 3/8” thread, stainless steel
- Counterweight: 3 lbs (1.35kg)
- Attaches to a camera tripod with 3/8” or 1/4” threads
- Includes 1.25" Stainless steel tripod (#3221)
- Includes Pier-extension (#8041)
- One year limited warranty on mount, 90 day for battery
Specifications....
Mount | Ultracompact GOTO EQ/AZ mount |
Payload (Max.) | 11 lbs (5kg), balanced |
Mount weight | 2.9 lbs (1.3kg) with battery |
Structure material | Metal frame structure |
Motor drive | Dual-axis DC servo motor with optical encoder |
Transmission | Synchronous belt |
Tracking speed | Solar, Lunar, Cel, 1/2 Cel, and N/S |
Maximum slew speed | 4.5°/sec (1080X) |
Worm period | 600 sec |
RA/DEC worm wheel | Φ77 mm, 144 teeth |
Hand controller | GoTo Nova 8410 - Optional |
Altitude adjustment range | 0º ~ 80º |
Azimuth adjustment range | ±5º |
Power Requirement | Internal rechargeable battery |
Battery type | Li-Poly, 3.7V, 2000mAh |
Duration of operation | Up to 10 hours at 20ºC |
Counterweigh Shaft | Φ20mmX200mm, 3/8" thread, stainless steel |
Counterweigh | 3 lbs (1.3 kg) |
Dovetail saddle | Vixen-type |
Body base connection | Vixen dovetail, 3/8” socket |
Power charge port | MiniUSB (5V) |
Wi-Fi | Built-in |
Communication port | Yes (Wi-Fi and USB) |
Firmware upgrade | Yes (via USB port) |
Tripod | 3221 Stainless Steel |
Pier extension | Φ80x190 mm, Included |
Operation Temperature | -10ºC ~40ºC |
Warranty | One year limited (90 day on battery) |
